ECM Mechanika MAX Espresso Machine

More photos (5)

Price

2 197,10 € incl. VAT

Manufacturer

ECM

Product code

82295

Weight

11 kg

The ECM Mechanika MAX (SKU 82295) is a compact heat-exchanger (HX) lever espresso machine with a quiet rotary pump and Smart HX PID control featuring a Flush advisor and adjustable pre-infusion. Stainless steel construction with an E61 brew group made of chromed brass, switchable between water tank and direct plumb-in. Shipped from an external warehouse within 24 hours from the EU, with expert technical support from our service technicians. More

Add to favourites Add to compare list Shipping and Payment

The ECM Mechanika MAX (SKU 82295) is the most compact HX lever espresso machine from ECM with a rotary pump. Inside its stainless steel frame sits a professional rotary pump that delivers maximum performance at minimal noise. It is designed for demanding home baristas who need stable extraction temperature, quiet operation, and the option of a direct plumbed-in water connection.

Key Features

🌡️ Smart HX with PID control

Smart HX extraction temperature management with a range of user-friendly functions via the PID controller.

💧 Flush advisor

Recommends the power and duration of the ideal flush based on the temperature you want to brew at.

🔧 E61 brew group

Top-tier ECM E61 brew group made of chromed brass for optimal extraction.

🔇 Quiet rotary pump

Rotary pump for quiet operation, switchable between water tank and direct plumb-in.

⏱️ Pre-infusion and timer

Both pre-infusion phases are adjustable, plus a shot timer displaying extraction time.

☕ Steam and hot water

Professional lever valves for steam and hot water, plus a burn-free steam wand.

The machine comes with two ergonomically angled ECM levers, weight-balanced in shape, and access to the water tank via a removable cup-warming tray.

Technical Specifications

Boiler type

Heat exchanger (HX)

Boiler volume

1.9 litres

Power input

1600 W

Brew group type

E61

Brew group material

Chromed brass

Pump type

Rotary

PID control

Yes

Shot timer

Yes

Steam wand

Yes (burn-free)

Hot water dispensing

Yes

Water source

Tank or direct plumb-in

Tank volume

3 litres

Dimensions (W × D × H)

275 × 445 × 405 mm

Weight

23.5 kg

Frame material

Steel

Product code

82295

Who It's For

✓

Home baristas who need precise, stable extraction temperature control via PID regulation.

✓

Those who want a quiet rotary pump instead of a noisy vibration pump.

✓

Kitchens with limited space, thanks to compact dimensions of 275 × 445 × 405 mm.

✓

Users who want to plumb the machine directly into the water line rather than refilling a tank.

✓

Milk-drink lovers, thanks to hot water dispensing and a burn-free steam wand.

Shipping and Returns

Shipped from an external warehouse within 24 hours (EU), with expert technical support from our service technicians. Unused goods can be returned within 14 days under the statutory right of withdrawal.

Frequently Asked Questions

What does heat exchanger (HX) technology mean on the ECM Mechanika MAX?

The 1.9-litre heat exchanger (HX) boiler allows you to brew espresso and steam milk at the same time. The ECM Mechanika MAX also adds Smart HX regulation with PID for more precise extraction temperature control.

Can I plumb the ECM Mechanika MAX directly into the water line?

Yes. The machine is switchable between a water tank (3-litre capacity) and a direct plumb-in connection, so you don't need to refill water manually.

How fast do you ship the machine, and can I return it?

We ship from an external warehouse within 24 hours within the EU. Unused goods can be returned within 14 days under the statutory right of withdrawal, and expert technical support from our service technicians is also available.
